The 500 LPH Mineral Water Plant is a complete commercial water purification solution designed to produce 500 liters of high-quality mineral drinking water per hour. It is ideal for businesses and industries that require a continuous supply of purified mineral water for drinking or bottling purposes. The plant combines advanced Reverse Osmosis (RO) technology, multi-stage filtration, UV sterilization, and a mineral dosing system to deliver crystal-clear, hygienic, and great-tasting drinking water.

This system is widely used in mineral water factories, bottling plants, schools, colleges, hospitals, restaurants, hotels, offices, factories, laboratories, housing societies, mosques, and commercial facilities where a reliable source of purified water is essential.

Manufactured using industrial-grade components, the plant offers excellent durability, high efficiency, low maintenance, and long-term performance. It effectively removes impurities while maintaining consistent water quality throughout continuous operation.

Key Features

• Produces 500 Liters Per Hour (LPH) of purified mineral water
• Advanced Reverse Osmosis (RO) purification technology
• Multi-stage filtration for maximum purification
• Removes up to 99% of dissolved impurities
• Eliminates bacteria, viruses, chlorine, heavy metals, and harmful chemicals
• Mineral dosing system restores essential minerals
• Improves taste, odor, and water clarity
• Heavy-duty stainless steel frame
• Energy-efficient operation
• Automatic and user-friendly control system
• High-quality RO membranes
• Easy installation and maintenance
• Suitable for continuous commercial operation
• Long service life with reliable performance

Typical Components Included

• Raw Water Feed Tank
• Raw Water Pump
• Multi Media Sand Filter
• Activated Carbon Filter
• Water Softener (Optional depending on feed water quality)
• Micron Cartridge Filter (5 Micron)
• Antiscalant Dosing System
• High Pressure Pump
• Reverse Osmosis Membrane Housing
• High-Rejection RO Membranes
• Flow Meters
• Pressure Gauges
• Conductivity/TDS Meter
• Mineral Dosing System
• UV Sterilizer
• Ozone Generator (Optional for Bottling Plants)
• Stainless Steel Piping
• Electrical Control Panel
• Stainless Steel Skid Frame

Filtration Process

1. Raw Water Tank

Stores incoming water before treatment and provides a continuous water supply to the system.

2. Multi Media Sand Filter

Removes sand, mud, suspended particles, rust, and sediments to protect downstream equipment.

3. Activated Carbon Filter

Eliminates chlorine, bad taste, unpleasant odor, pesticides, and organic contaminants.

4. Water Softener (Optional)

Removes hardness-causing minerals such as calcium and magnesium to extend membrane life.

5. Micron Cartridge Filter

Captures fine particles before water enters the RO membranes.

6. High Pressure Pump

Provides the required pressure for the Reverse Osmosis membranes.

7. Reverse Osmosis Membrane

Removes dissolved salts (TDS), bacteria, viruses, fluoride, arsenic, nitrates, heavy metals, and other harmful contaminants.

8. Mineral Dosing System

Adds healthy minerals such as calcium and magnesium to improve taste and maintain balanced drinking water.

9. UV Sterilizer

Kills remaining bacteria, viruses, and microorganisms using ultraviolet light.

10. Ozone System (Optional)

Provides additional disinfection for bottled water and increases shelf life.

How Does the 500 LPH Mineral Water Plant Work?

The mineral water plant begins by collecting raw water in a storage tank. The water first passes through a Multi Media Sand Filter, which removes larger suspended particles such as sand, dust, and rust. It then flows into an Activated Carbon Filter, where chlorine, odors, bad taste, and organic impurities are removed.

If the source water contains excessive hardness, it passes through a Water Softener to reduce calcium and magnesium levels. Next, the water enters a Micron Cartridge Filter, which traps very fine particles and protects the RO membranes.

A High Pressure Pump then forces the water through Reverse Osmosis Membranes. These membranes remove up to 99% of dissolved salts (TDS), bacteria, viruses, heavy metals, fluoride, arsenic, nitrates, and harmful chemicals, producing highly purified water.

Since RO also removes beneficial minerals, the purified water is passed through a Mineral Dosing System, where essential minerals are added back to improve taste and nutritional value.

Finally, the water passes through a UV Sterilizer (and optionally an Ozone Generator) to ensure complete disinfection before it is stored in a clean water tank or transferred directly to the bottling line.

The result is fresh, hygienic, healthy, and great-tasting mineral drinking water that meets commercial quality standards.

Applications

• Mineral Water Bottling Plants
• Drinking Water Factories
• Commercial Water Plants
• Schools
• Colleges
• Universities
• Hospitals
• Clinics
• Hotels
• Restaurants
• Offices
• Shopping Malls
• Industrial Facilities
• Laboratories
• Mosques
• Housing Societies

Benefits

• Produces premium-quality mineral drinking water
• Excellent purification efficiency
• Removes harmful contaminants effectively
• Improves taste and water quality
• Continuous commercial water production
• Energy-efficient operation
• Low operating and maintenance costs
• Durable industrial construction
• Reliable long-term performance
• Ideal for commercial and industrial use

Frequently Asked Questions (FAQs)

Q1. What is the production capacity of this plant?

A: This plant produces up to 500 liters of purified mineral water per hour (500 LPH), depending on feed water quality and operating conditions.

Q2. Does it remove bacteria and viruses?

A: Yes. The RO membrane removes most microorganisms, while the UV sterilizer provides additional protection by disinfecting the water.

Q3. Is a mineral dosing system included?

A: Yes. The plant includes a mineral dosing system that restores essential minerals such as calcium and magnesium after RO purification.

Q4. Can this plant be used for bottled water production?

A: Yes. It is suitable for mineral water bottling businesses and can also be integrated with bottle rinsing, filling, and capping machines.

Q5. Does it reduce TDS?

A: Yes. The Reverse Osmosis system effectively reduces high TDS levels and removes dissolved impurities from the water.

Q6. Is it suitable for commercial use?

A: Yes. The 500 LPH Mineral Water Plant is specifically designed for commercial and industrial applications that require continuous purified water production.

Q7. How often should filters and membranes be replaced?

A: Pre-filters are generally replaced every 3–6 months, while RO membranes typically last 2–3 years, depending on feed water quality and maintenance.

Q8. Does the system require regular maintenance?

A: Yes. Routine cleaning, filter replacement, membrane inspection, and sanitization help maintain optimal performance and extend the plant’s lifespan.
